13 Liter Refrigerated Open Bath

13 L, Refrigerated Open Bath

Select voltage
$1,989.00
T13RS

Key Specifications

Description

13 L, Refrigerated Open Bath

Working Temperature Range °C
0° to 150°
Working Access (L x W x D) (cm)
22.9 x 29.8 x 19.7 cm
Flammability Class (DIN 12876-1)
I (NFL)

Key Features

  • Continuous cooling to 0°C
  • Designed to run at maximum cooling; required heated thermostat for temperature control
  • Ideal for applications where bath temperatures at or near ambient are required
  • Insulated stainless steel tank
  • Cool Command™

Common Specifications

Working Temperature Range °F
32° to 302°
Working Temperature Range °C
0° to 150°
Reservoir Capacity (gallons)
3.4
Reservoir Capacity (liters)
13
Reservoir/Tank Material
Stainless Steel
Working Access (L x W x D) (inches)
9 x 11.75 x 7.75 in
Working Access (L x W x D) (cm)
22.9 x 29.8 x 19.7 cm
Flammability Class (DIN 12876-1)
I (NFL)
Maximum Ambient Temperature °F
95°
Maximum Ambient Temperature °C
35°
Overall Dimensions (L x W x H) (inches)
13.5 x 22 x 10 in
Overall Dimensions (L x W x H) (cm)
34.3 x 55.9 x 25.4 cm
Shipping Weight (pounds)
58.0
Shipping Weight (kilograms)
26.0
Catalog Page Number
75

60 Hz Only

Part Number
T13RSA11B
Cooling Capacity @ 0°C (W) 90
Cooling Capacity @ +10°C (W) 270
Cooling Capacity @ +20°C (W)
400
Electrical Requirements (VAC/Hz/Ph/A)
120/60/1/13

50 Hz Only

Part Number
T13RSA12E
Cooling Capacity @ 0°C (W)
75
Cooling Capacity @ +10°C (W) 225
Cooling Capacity @ +20°C (W)
330
Electrical Requirements (VAC/Hz/Ph/A)
240/50/1/1.5
Regulatory Approvals
CE
